The NPS Pump stands as a cutting-edge single-stage, double-suction horizontal split-case centrifugal pump, delivering remarkable performance and reliability. Let’s delve deeper into its specifications
Applications:
The NPS Pump serves as an invaluable asset across a multitude of applications, making it an indispensable choice for numerous industries and fluid transfer scenarios, including:
Fire Service / Municipal Water Supply / Dewatering Processes / Mining Operations / Paper Industry / Metallurgy Industry / Thermal Power Generation / Water Conservancy Projects
The NPS Pump's remarkable features, extensive capacity, and adaptability make it a dependable and versatile choice for a wide array of industries and fluid transfer requirements.
It is designed to transfer liquid with temperature from -20℃ to 80℃ and PH value from 5 to 9. The working pressure (inlet pressure plus pumping pressure) of the pump made of normal materials is 1.6Mpa. The highest working pressure can be 2.5 Mpa by changing the materials of pressure-bearing parts.
Characteristics
● Single stage double suction horizontal split case centrifugal pump
● Enclosed impellers, double suction provides hydraulic balance eliminating axial thrust
● Standard design for Clockwise viewed from coupling side ,also counter-clockwise rotation is available
● Diesel engine starting, also electrical and turbine is available
● High energy efficiency, low cavitation
Material
Casing/Cover：
● Cast iron, Ductile iron, Cast steel
Impeller:
● Cast iron, Ductile iron, cast steel, stainless steel, bronze
Main shaft:
● Stainless steel, 45steel
Sleeve：
● Cast iron, Stainless steel
Seal rings：
● Cast iron, Ductile iron, bronze, stainless steel
